前照灯检测仪FLG-600M
category:Light detector page view:4
FLG-600M前照灯检测仪用于对机动车前照灯的远、近光灯发光强度以及光轴偏移量的测量。适用于机动车修理厂、机动车检测站、汽车制造厂对机动车前照灯进行检测与调整。
注:规格如有变动,我司恕不另行通知。
-
◆光学成像找正前照灯灯具中心,操作直观简捷;
◆平衡配重,上下行省力;
◆远光灯、近光灯发光强度及光轴偏移量同时测定,数字显示。
◆采用先进光学系统结构,可将被检测前照灯配光特性展示在仪器屏幕上,方便观察与前照灯调整。
◆配RS-232串口通讯接口,方便数据送上位机处理。
◆可选配导轨。
-
测量范围 Measuring range
发光强度
Luminous intensity
光轴偏移量
Deviation from the optical axis
0~60000cd
垂直方向
Vertical direction
上1°30′~下2°30′或上20cm/10m~下40cm/10m
水平方向
Horizontal direction
左2°30′~右2°30′或左40cm/10m~右40cm/10m
示值误差
Indication error
检测距离
Measuring distance
导轨长度
Length of the rail
环境温度
℃
相对湿度
%
发光强度:±10%
Indication error of luminous intensity
0.5m
4.5m(选配)
(5~40)℃
20%~90%
光轴偏移量:±15′
Deviation error from the optical axis
电源Power:AC220V±10%,50Hz±1%
灯高范围:500~1300mm
Measuring range of lamp height
重量Wet:40kg(主机)
